ASME B16.11 - svikin festingar, fals-suðu og snittari

Feb 26, 2026

ASME B16.11 er staðall fyrir innstungusuðu og snittari svikin stálpíputengi. Þrýstieinkunnir eru flokkar 2000, 3000, 6000 og 9000. Stærðir eru á bilinu NPS 1/8 til NPS 4 (DN 6 til DN 100), hentugur fyrir smíðuð píputengi með litlum-þvermáli sem notuð eru í háum-þrýstingi, háum{13}hitaumhverfi.

ASME B16.11 Forged Fittings

ANSI B16 11 þrýstieinkunnir festinga

Þráðarfestingar: Class 2000, 3000, 6000 psi
Innstunga-Suðufestingar: Class 3000, 6000, 9000 psi

ANSI B 16.11 Gerðir rörtengia

Olnbogar: 45 gráður, 90 gráður
Teigur, krossar
Tengingar, Minnkandi tengi
Húfur, yfirmenn
Innstunga, Bushing
Geirvörta

ASTM B1611 Socket-Welding Elbows Tees and Crosses

Nafnstærð		Þvermál falshols	Borþvermál festinga			Veggþykkt fals						Líkamsveggur			Dýpt fals	Miðja til botns á innstungunni
DN	NPS	B	D			C						G_mín			J_mín	A
			3000	6000	9000	3000		6000		9000		3000	6000	9000		90 gráðu olnbogi, teigur, kross			45 gráðu olnbogi
			3000	6000	9000	Meðaltal	Min	Meðaltal	Min	Meðaltal	Min	3000	6000	9000		3000	6000	9000	3000	6000	9000
6	1/8	10.9	6.1	3.2	-	3.18	3.18	3.96	3.43	-	-	2.41	3.15	-	9.5	11.0	11.0	-	8.0	8.0	-
8	1/4	14.3	8.5	5.6	-	3.78	3.30	4.60	4.01	-	-	3.02	3.68	-	9.5	11.0	13.5	-	8.0	8.0	-
10	3/8	17.7	11.8	8.4	-	4.01	3.50	5.03	4.37	-	-	3.20	4.01	-	9.5	13.5	15.5	-	8.0	11.0	-
15	1/2	21.9	15.0	11.0	5.6	4.67	4.09	5.97	5.18	9.53	8.18	3.73	4.78	7.47	9.5	15.5	19.0	25.5	11.0	12.5	15.5
20	3/4	27.3	20.2	14.8	10.3	4.90	4.27	6.96	6.04	9.78	8.56	3.91	5.56	7.82	12.5	19.0	22.5	28.5	13.0	14.0	19.0
25	1	34.0	25.9	19.9	14.4	5.69	4.98	7.92	6.93	11.38	9.96	4.55	6.35	9.09	12.5	22.5	27.0	32.0	14.0	17.5	20.5
32	1_1/4	42.8	34.3	28.7	22.0	6.07	5.28	7.92	6.93	12.14	10.62	4.85	6.35	9.70	12.5	27.0	32.0	35.0	17.5	20.5	22.5
40	1_1/2	48.9	40.1	33.2	27.2	6.35	5.54	8.92	7.80	12.70	11.12	5.08	7.14	10.15	12.5	32.0	38.0	38.0	20.5	25.5	25.5
50	2	61.2	51.7	42.1	37.4	6.93	6.04	10.92	9.50	13.84	12.12	5.54	8.74	11.07	16.0	38.0	41.0	54.0	25.5	28.5	28.5
65	2_1/2	73.9	61.2	-	-	8.76	7.62	-	-	-	-	7.01	-	-	16.0	41.0	-	-	28.5	-	-
80	3	89.9	76.4	-	-	9.52	8.30	-	-	-	-	7.62	-	-	16.0	57.0	-	-	32.0	-	-
100	4	115.5	100.7	-	-	10.69	9.35	-	-	-	-	8.56	-	-	19.0	66.5	-	-	41.0	-	-

ATH: Mál eru í millimetrum.

ASME B1611 Threaded 45 Elbow 90 Elbow Tee Cross

Nafnstærð		Miðstöð til enda						Ytri þvermál að bandi			Veggþykkt			Lengd þráðar
DN	NPS	A						H			G_mín			L5_mín	L2_mín
		90 gráðu olnbogar teigar Krossar			45 gráðu olnbogar			H			G_mín
		2000	3000	6000	2000	3000	6000	2000	3000	6000	2000	3000	6000
6	1/8	21	21	25	17	17	19	22	22	25	3.18	3.18	6.35	6.4	6.7
8	1/4	21	25	28	17	19	22	22	25	33	3.18	3.30	6.60	8.1	10.2
10	3/8	25	28	33	19	22	25	25	33	38	3.18	3.51	6.98	9.1	10.4
15	1/2	28	33	38	22	25	28	33	38	46	3.18	4.09	8.15	10.9	13.6
20	3/4	33	38	44	25	28	33	38	46	56	3.18	4.32	8.53	12.7	13.9
25	1	38	44	51	28	33	35	46	56	62	3.68	4.98	9.93	14.7	17.3
32	1_1/4	44	51	60	33	35	43	56	62	75	3.89	5.28	10.59	17.0	18.0
40	1_1/2	51	60	64	35	43	44	62	75	84	4.01	5.56	11.07	17.8	18.4
50	2	60	64	83	43	44	52	75	84	102	4.27	7.14	12.09	19.0	19.2
65	2_1/2	76	83	95	52	52	64	92	102	121	5.61	7.65	15.29	23.6	28.9
80	3	86	95	106	64	64	79	109	121	146	5.99	8.84	16.64	25.9	30.5
100	4	106	114	114	79	79	79	146	152	152	6.55	11.18	18.67	27.7	33.0

ASME B1611 Thread Street 90 Elbows

Nafnstærð		Miðja til kvenkyns End		Miðja til karlkyns End		Ytri þvermál að bandi		Veggþykkt		Veggþykkt		Lengd kvenkyns þráðar		Lengd karlþráðs
DN	NPS	A		J		H		G_{1 mín}		G_{2 mín}		L_{5 mín}	L_{2 mín}	L_mín
DN	NPS	3000	6000	3000	6000	3000	6000	3000	6000	3000	6000	L_{5 mín}	L_{2 mín}	L_mín
6	1/8	19	22	25	32	19	25	3.18	5.08	2.74	4.22	6.4	6.7	10
8	1/4	22	25	32	38	25	32	3.30	5.66	3.22	5.28	8.1	10.2	11
10	3/8	25	28	38	41	32	38	3.51	6.98	3.50	5.59	9.1	10.4	13
15	1/2	28	35	41	48	38	44	4.09	8.15	4.16	6.53	10.9	13.6	14
20	3/4	35	44	48	57	44	51	4.32	8.53	4.88	6.86	12.7	13.9	16
25	1	44	51	57	66	51	62	4.98	9.93	5.56	7.95	14.7	17.3	19
32	11/4	51	54	66	71	62	70	5.28	10.59	5.56	8.48	17.0	18.0	21
40	11/2	54	64	71	84	70	84	5.56	11.07	6.25	8.89	17.8	18.4	21
50	2	64	83	84	105	84	102	7.14	12.09	7.64	9.70	19.0	19.2	22

ASME B1611 Threaded Cap Half-Coupling Threadolet Coupling

Nafnstærð		Enda-til-enda	Enda-til-enda		Ytri þvermál		Endaveggur		Lengd þráðar
DN	NPS	W	P		D		G		L_{5 mín}	L_{2 mín}
DN	NPS	3000 & 6000	3000	6000	3000	3000	3000	3000	L_{5 mín}	L_{2 mín}
6	1/8	32	19	-	16	22	4.8	-	6.4	6.7
8	1/4	35	25	27	19	25	4.8	6.4	8.1	10.2
10	3/8	38	25	27	22	32	4.8	6.4	9.1	10.4
15	1/2	48	32	33	28	38	6.4	7.9	10.9	13.6
20	3/4	51	37	38	35	44	6.4	7.9	12.7	13.9
25	1	60	41	43	44	57	9.7	11.2	14.7	17.3
32	1_1/4	67	44	46	57	64	9.7	11.2	17.0	18.0
40	1_1/2	79	44	48	64	76	11.2	12.7	17.8	18.4
50	2	86	48	51	76	92	12.7	15.7	19.0	19.2
65	2_1/2	92	60	64	92	108	15.7	19.0	23.6	28.9
80	3	108	65	68	108	127	19.0	22.4	25.9	30.5
100	4	121	68	75	140	159	22.4	28.4	27.7	33.0

ASME B1611 SW Coupling SW Half Coupling BOSS SW Cap Lateral

Nafnstærð		Þvermál falshols	Borþvermál festinga			Veggþykkt fals						Líkamsveggur			Min. Dýpt af innstungu	Lagningarlengdir	Lagningarlengdir	Endurveggþykkt			Miðja til botns á innstungunni
DN	NPS	B	D			C						G_mín			J_mín	E	F	K_mín			A		H
			3000	6000	9000	3000		6000		9000		3000	6000	9000				3000	6000	9000	3000	6000	3000	6000
			3000	6000	9000	Meðaltal	Min	Meðaltal	Min	Meðaltal	Min	3000	6000	9000				3000	6000	9000	3000	6000	3000	6000
6	1/8	10.9	6.1	3.2	-	3.18	3.18	3.96	3.43	-	-	2.41	3.15	-	9.5	6.5	16.0	4.8	6.4	-	-	-	-	-
8	1/4	14.3	8.5	5.6	-	3.78	3.30	4.60	4.01	-	-	3.03	3.68	-	9.5	6.5	16.0	4.8	6.4	-	-	-	-	-
10	3/8	17.7	11.8	8.4	-	4.01	3.50	5.03	4.37	-	-	3.20	4.01	-	9.5	6.5	17.5	4.8	6.4	-	37	-	9.5	-
15	1/2	21.9	15.0	11.0	5.6	4.67	4.09	5.97	5.18	9.53	8.18	3.73	4.78	7.47	9.5	9.5	22.5	6.4	7.9	11.2	41	51	9.5	11
20	3/4	27.3	20.2	14.8	10.3	4.90	4.27	6.96	6.04	9.78	8.56	3.91	5.56	7.82	12.5	9.5	24.0	6.4	7.9	12.7	51	60	11	13
25	1	34.0	25.9	19.9	14.4	5.69	4.98	7.92	6.93	11.38	9.96	4.55	6.35	9.09	12.5	12.5	28.5	9.6	11.2	14.2	60	71	13	16
32	11/4	42.8	34.3	28.7	22.0	6.07	5.28	7.92	6.93	12.14	10.62	4.85	6.35	9.70	12.5	12.5	30.0	9.6	11.2	14.2	71	81	16	17
40	11/2	48.9	40.1	33.2	27.2	6.35	5.54	8.92	7.80	12.70	11.12	5.08	7.14	10.15	12.5	12.5	32.0	11.2	12.7	15.7	81	98	17	21
50	2	61.2	51.7	42.1	37.4	6.93	6.04	10.92	9.50	13.85	12.12	5.54	8.74	11.07	16.0	19.0	41.0	12.7	15.7	19.0	98	151	21	30
65	21/2	73.9	61.2	-	-	8.76	7.62	-	-		-	7.01	-	-	16.0	19.0	43.0	15.7	19.0	-	151	-	30	-
80	3	89.9	76.4	-	-	9.52	8.30	-	-		-	7.63	-	-	16.0	19.0	44.5	19.0	32.4	-	184	-	57	-
100	4	115.5	100.7	-	-	10.69	9.35	-	-		-	8.56	-	-	19.0	19.0	48.0	22.4	28.4	-	201	-	66	-

ASME B1611 Plug Bushing

Nafnstærð		Lengd	Ferningshæð	Breiddar íbúðir	Þvermál höfuð	Lengd	Hex hæð	Hex hæð	Hex hæð
DN	NPS	A_mín	B_mín	C_mín	E_mín	D_mín	H_mín	G_mín	F_mín
6	1/8	10	6	7	10	35	6	一	11
8	1/4	11	6	10	14	41	6	3	16
10	3/8	13	8	11	18	41	8	4	18
15	1/2	14	10	14	21	44	8	5	22
20	3/4	16	11	16	27	44	10	6	27
25	1	19	13	21	33	51	10	6	36
32	1_1/4	21	14	24	43	51	14	7	46
40	1_1/2	21	16	28	48	51	16	8	50
50	2	22	18	32	60	64	18	9	65
65	2_1/2	27	19	36	73	70	19	10	75
80	3	28	21	41	89	70	21	10	90
100	4	32	25	65	114	76	25	13	115

ASME B1611 Concentric Eccentric Swaged Nipple

Nafnstærð		ODí lokin	Lengdaf lítillenda	Endaað enda
DN	NPS	OD₁×OD₂	SL_mín	A
8×6	1/4×1/8	13.7×10.3	20	57
10×6	3/8×1/8	17.1×10.3	20	64
10×8	3/8×1/4	17.1×13.7	20	64
15×6	1/2×1/8	21.3×10.3	20	70
15×8	1/2×1/4	21.3×13.7	20
15×10	1/2×3/8	21.3×17.1	20
20×6	3/4×1/8	26.7×10.3	20	76
20×8	3/4×1/4	26.7×13.7	20
20×10	3/4×3/8	26.7×17.1	22
20×15	3/4×1/2	26.7×21.3	22
25×6	1×1/8	33.4×10.3	20	89
25×8	1×1/4	33.4×13.7	20
25×10	1×3/8	33.4×17.1	22
25×15	1×1/2	33.4×21.3	22
25×20	1×3/4	33.4×26.7	22
32×6	11/4×1/8	42.2×10.3	20	102
32×8	11/4×1/4	42.2×13.7	20
32×10	11/4×3/8	42.2×17.1	22
32×15	11/4×1/2	42.2×21.3	22
32×20	11/4×3/4	42.2×26.7	25
32×25	11/4×1	42.2×33.4	25
40×6	11/2×1/8	48.3×10.3	20	114
40×8	11/2×1/4	48.3×13.7	20
40×10	11/2×3/8	48.3×17.1	22
40×15	11/2×1/2	48.3×21.3	25
40×20	11/2×3/4	48.3×26.7	25
40×25	11/2×1	48.3×33.4	25
40×32	11/2×11/4	48.3×42.2	25
50×6	2×1/8	60.3×10.3	20	165
50×8	2×1/4	60.3×13.7	22
50×10	2×3/8	60.3×17.1	22
50×15	2×1/2	60.3×21.3	25
50×20	2×3/4	60.3×26.7	30
50×25	2×1	60.3×33.4	30
50×32	2×11/4	60.3×42.2	30
50×40	2×11/2	60.3×48.3	30
100×40	4×11/2	114.3×48.3	40	229
100×50	4×2	114.3×60.3	45
100×65	4×21/2	114.3×73.0	45
100×80	4×3	114.3×88.9	45
100×90	4×31/2	114.3×101.6	45
125×8	5×1/4	141.3×13.7	25	279
125×10	5×3/8	141.3×17.1	25
125×15	5×1/2	141.3×21.3	25
125×20	5×3/4	141.3×26.7	30
125×25	5×1	141.3×33.4	30
125×32	5×11/4	141.3×42.2	40
125×40	5×11/2	141.3×48.3	40
125×50	5×2	141.3×60.3	45
125×65	5×21/2	141.3×73.0	45
125×80	5×3	141.3×88.9	45
125×90	5×31/2	141.3×101.6	45
125×100	5×4	141.3×114.3	50
150×15	6×1/2	168.3×21.3	30	304
150×20	6×3/4	168.3×26.7	30
150×25	6×1	168.3×33.4	40
150×32	6×11/4	168.3×42.2	40
150×40	6×11/2	168.3×48.3	45
150×50	6×2	168.3×60.3	45
150×65	6×21/2	168.3×73.0	45
150×80	6×3	168.3×88.9	45
150×90	6×31/2	168.3×101.6	50
150×100	6×4	168.3×114.3	50
150×125	6×5	168.3×141.3	60

ASME B16.11 Sockolet and Threadolet

ASME B16.11 SOCKOLET

Nafnstærð		Útibúpípa nafnstærð		Dýpt á fals	Andlit á mátun að halla sér		Dimetraaf mátun		Veggþykkt fals		Gat þvermál
DN	NPS	DN	NPS	J_mín	A_hámark		D_hámark		C_mín		d1 nafn
DN	NPS	DN	NPS	J_mín	3000	6000	3000	6000	3000	6000	3000	6000
8-900	1/4-36	6	1/8	9.5	10	一	27	一	3.18	一	16	一
10-900	3/8-36	8	1/4	9.5	10	一	27	一	3.78	一	16	一
15-900	1/2-36	10	3/8	9.5	13	一	30	一	4.01	一	19	一
20-900	3/4-36	15	1/2	9.5	16	24	38	47	4.67	5.97	24	19
25-900	1-36	20	3/4	12.5	16	25	47	53	4.90	6.96	30	25
32-900	1_1/4-36	25	1	12.5	22	29	56	63	5.69	7.92	36	33
40-900	1_1/2-36	32	1_1/4	12.5	22	30	66	74	6.07	7.92	45	38
50-900	2-36	40	1_1/2	12.5	24	32	75	83	6.35	8.92	51	49
65-900	2_1/2-36	50	2	16.0	24	37	90	104	6.93	10.92	65	59
80-900	3-36	65	2_1/2	16.0	25	一	105	一	8.76	一	76	一
100-900	4-36	80	3	16.0	30	一	124	一	9.52	一	94	一
125-900	5-36	100	4	19.0	30	一	154	一	10.69	一	121	一

ASME B16.11 ÞREADOLET

Keyra pípa nafnstærð		Útibúpípa nafnstærð		Andlit á mátun að halla sér		Þvermál festingar		Þvermál a hafa tilhneigingu til greinarpípa		Lengd á þráður	Gat þvermál
DN	NPS	DN	NPS	A		D1_mín		D2_mín		L2_mín	d1 nafn
DN	NPS	DN	NPS	3000	6000	3000	6000	3000	6000	L2_mín	3000	6000
8-900	1/4-36	6	1/8	19	一	27	一	22	一	6.7	16	一
10-900	3/8-36	8	1/4	19	一	27	一	22	一	10.2	16	一
15-900	1/2-36	10	3/8	21	一	30	一	25	一	10.4	19	一
20-900	3/4-36	15	1/2	25	32	38	45	33	42	13.6	24	19
25-900	1-36	20	3/4	27	37	47	52	39	48	13.9	30	25
32-900	1_1/4-36	25	1	33	40	56	63	48	58	17.3	36	33
40-900	1_1/2-36	32	1_1/4	33	41	66	72	58	67	18.0	45	38
50-900	2-36	40	1_1/2	35	43	75	83	64	77	18.4	51	49
65-900	2_1/2-36	50	2	38	52	90	104	77	93	19.2	65	59
80-900	3-36	65	2_1/2	46	一	105	一	94	一	28.9	76	一
100-900	4-36	80	3	51	一	124	一	114	一	30.5	94	一
125-900	5-36	100	4	57	一	154	一	140	一	33.0	121	一

ASME B16.11 Weldolet

Keyra pípa nafnstærð		Útibúpípa nafnstærð		Lengdir			Þvermál á mátun			Gat þvermál
DN	NPS	DN	NPS	A			D2mín			d1nom
DN	NPS	DN	NPS	STD	XS	Sch160	STD	XS	Sch160	STD	XS	Sch160
8-900	1/4-36	6	1/8	16	16	一	24	42	一	16	16	一
10-900	3/8-36	8	1/4	16	16	一	26	26	一	16	16	一
15-900	1/2-36	10	3/8	19	19	一	30	30	一	19	19	一
20-900	3/4-36	15	1/2	19	19	28	36	36	36	24	24	14
25-900	1-36	20	3/4	22	22	32	43	43	46	30	30	19
32-900	11/4-36	25	1	27	27	38	55	55	51	36	36	25
40-900	11/2-36	32	11/4	32	32	44	66	66	63	45	45	33
50-900	2-36	40	11/2	33	33	51	74	74	71	51	51	38
65-900	21/2-36	50	2	38	38	55	90	90	82	65	65	43
80-900	3-36	65	21/2	41	41	62	104	104	98	76	76	54
90-900	31/2-36	80	3	44	44	73	124	124	122	93	93	73
100-900	4-36	90	31/2	48	48	一	138	138	一	113	113	一
125-900	5-36	100	4	51	51	84	154	154	154	120	120	98
150-900	6-36	125	5	57	57	94	187	187	188	141	141	122
200-900	8-36	150	6	60	78	105	213	227	222	170	170	146
250-900	10-36	200	8	70	99	一	265	292	一	220	220	一
300-900	12-36	250	10	78	94	一	323	325	一	275	265	一
350-900	14-36	300	12	86	103	一	379	381	一	325	317	一
400-900	16-36	350	14	89	100	一	411	416	一	357	351	一
450-900	18-36	400	16	94	106		465	468	一	408	403
500-900	20-36	450	18	97	111	一	522	525	一	459	455	一
550-900	22-36	500	20	102	119	一	573	584	一	508	509	一
650-900	26-36	600	24	116	140	一	690	708	一	614	612	一

Fylgni innréttingaflokks við áætlunarnúmer eða veggtilnefningu rörs fyrir útreikning á einkunnum

Flokkurheiti innréttinga

Tegund festingar

Pípa Notað fyrir einkunnagrundvöll

Dagskrá nr.

Veggmerki

2000

3000

6000

3000

6000

9000

Þráður

Innstungu-suðu

160

...

160

...

XXS

...

XXS

Nafnveggþykkt áætlunar 160 og tvöfaldur extra sterkur pípa

NPS

Dagskrá 160

XXS

Í.

1/8

1/4

3/8

3.15

3.68

4.01

0.124

0.145

0.158

4.83

6.05

6.40

0.190

0.238

0.252

ASME B16.11 - svikin festingar, fals-suðu og snittari

ASME B16.11 forskrift fyrir svikin festingar, fals-suðu og snittari

ASME B16.11 fals-Suðu olnboga, teiga og krossa

ASME B16.11 snittari 45 gráðu olnbogi, 90 gráðu olnbogi, teigur, kross

ASME B16.11 Street 90 gráðu olnbogar

ASME B16.11 loki, hálf-tengi, þráður, tengi

ASME B16.11 SW tenging, hálf tenging, BOSS, húfa, hlið

ASME B16.11 ferningahaustappi, sléttunarrússa, kringlótt höfuðtappi, sexkantstappi, sexkantshaus

ASME B16.11 Concentric sérvitringur með snertingu

ASME B16.11 fals og þráður

ASME B16.11Weldolet
